Hydrocarbon Resin C5(Aliphatic C5 Resin)
C5 Resin (C5 hydrocarbon resin) is a low-molecular-weight, aliphatic thermoplastic obtained by cationic polymerization of the C5 fraction (isoprene, piperylene, cyclopentadiene, etc.) produced during petroleum cracking. It comes as pale-yellow to water-white granules with a softening point of 80–110 °C and is odorless and non-toxic.
Key features:
- Excellent compatibility with natural rubber, SIS/SBS, EVA, APAO and other elastomers
- Markedly boosts tack, peel strength and low-temperature performance
- Resistant to acids, alkalis and water; good electrical insulation
Main applications:
1. Hot-melt adhesives (packaging, hygiene, labels) – provides tack and open time
2. Pressure-sensitive adhesives (tapes, stickers) – adjusts peel force
3. Road-marking paints – improves adhesion of glass beads and wear resistance
4. Tires and rubber goods – acts as tackifier/plasticizer
5. Construction sealants and waterproof membranes – enhances flexibility and adhesion
In short: C5 resin is the “tack catalyst” that makes adhesives, paints and rubber stick faster, stronger and longer.

Hydrocarbon Resin C5 Resin List:
| Item | Softening Point (°C) | Color Gardner |
Acid Value (Mg KOH/g) |
Specific Gravity (20/20°C) | Melt Viscosity (BRF, @200°C, cps) |
| Test Method | ASTM E 28 | ASTM D 1544 | ASTM D 974 | ASTM D 71 | ASTM D 3236 |
| HC 5100 | 95-105 | #3-5 | ≤1.0 | 0.92-0.99 | 200 max |
| HC 52100A | 95-105 | #3-5 | ≤1.0 | 0.92-0.99 | 200 max |
| DCPD RESIN | 95-120 | #0-3 | ≤0.05 | 0.92-0.99 | 170 max |
| HC 5090 | 85-95 | #4 | ≤1.0 | 0.92-0.99 | 200 max |
| HC 52100 | 100-105 | #3-4 | ≤1.0 | 0.92-0.99 | 250 max |
Application:
| Type Recommended |
Basic Polymer | Application |
| HC 5100 | NR SIS SBS | Masking/Packaging Tape |
| HC 5100, HC 5090 | NR SIS SBS | Pressure Sensitive Adhesive |
| HC 5100, HC 5090 | EVA | HMA |
| HC 5100 | EVA | Bookbinding HMA |
| HC 52100, HC 52100A | FILLERS | Thermoplastic Road Marking Paint |
| HC 52100, HC5100 | BUTYL RUBBER | Sealants |
| DCPD, HC 5100, HC 52100 | NR BR SBR | Rubber Compounding |
