Aliphatic Hydrocarbon Resin HC5100 for Rubber Application
Product Name:Aliphatic Hydrocarbon Resin,Piperylene-based Hydrocarbon Resin,or Distillates (petroleum), steam-cracked C5 fraction, polymerized; Hydrogenated C5 Hydrocarbon Resin,Piperylene-based Hydrocarbon Resin
Key Benefits
- Excellent compatibility with NR, SBR, BR, CR; 3–8 phr raises green tack 30–60 %
- Reduces Mooney viscosity 20–40 MU, cuts mixing time ~15 %, improves filler dispersion
- No influence on cure curve; ≥95 % retention of tensile & tear after vulcanization; heat-aging (100 °C×24 h) stable
- Low VOC, odor-free, REACH/RoHS compliant
Specification:
| Test Item | Specification | Test Method |
| Appearance | Pale Yellow Granule | Eyeballing |
| Softening Point(°C) | 95-105 | ASTM E 28 |
| Color Gardner | # 4-5 | ASTM D 974 |
| Acid Value (KOH mg/g) | ≤1.0 or ≤0.1 | ASTM D 1544 |
| Ash Content%(wt) | ≤0.1 | ASTM D 1063 |
Recommended Loading
- Footwear (sole, foxing) ................ 5–8 phr
- Rubber goods (sheet, roller, belt) ..... 4–8 phr
- └─ Tire tread
- ‑ Passenger / light-truck .............. 4–6 phr
- ‑ Truck / bus .......................... 6–8 phr
Processing Note:
Add together with rubber; no need to modify cure system. Store in a cool, dry place away from direct sunlight.
Hydrocarbon Resin C5 List:
| Application |
Base Polymer Main Content
|
Product Recommended |
| Masking/Packaging Tape | NR SIS SBS | HC5100 |
| Pressure Sensitive Adhesive | NR SIS SBS | HC5100, HC5090 |
| HMA | EVA | HC5100, HC5090 |
| Bookbinding HMA | EVA | HC5100 |
| Thermoplastic Road Marking Paint | FILLERS | HC52100, HC52100A |
| Sealants | BUTYL RUBBER | HC52100, HC5100 |
| Rubber Compounding | NR BR SBR | DCPD, HC5100, HC52100 |
