HC5100 Aliphatic Hydrocarbon Resin C5（Rubber Grade）

HC5100 is a light-colored C5 hydrocarbon resin with a softening point around 100 °C; it exhibits excellent compatibility with NR, SBR and BR. Adding 3–8 phr during rubber compounding markedly improves tack, green strength and elongation without affecting cure rate, making it a highly efficient, eco-friendly tackifier for tires, shoe soles and conveyor belts.

Item NO.:
HC5100(Rubber Grade)
EINECS No.:
265-116-8
CAS No.:
64742-16-1
Color Gardener:
#4-5
Property:
C5 Hydrocarbon Resin – Tackifier for Footwear, General Rubber Goods & Tire Tread

Inquiry now

Product Detail
Packaging and Transportation

Aliphatic Hydrocarbon Resin HC5100 for Rubber Application

Petroleum Hydrocarbon Resin C5

Product Name:Aliphatic Hydrocarbon Resin,Piperylene-based Hydrocarbon Resin,or Distillates (petroleum), steam-cracked C5 fraction, polymerized; Hydrogenated C5 Hydrocarbon Resin,Piperylene-based Hydrocarbon Resin

Key Benefits

Excellent compatibility with NR, SBR, BR, CR; 3–8 phr raises green tack 30–60 %
Reduces Mooney viscosity 20–40 MU, cuts mixing time ~15 %, improves filler dispersion
No influence on cure curve; ≥95 % retention of tensile & tear after vulcanization; heat-aging (100 °C×24 h) stable
Low VOC, odor-free, REACH/RoHS compliant

Specification:

Test Item	Specification	Test Method
Appearance	Pale Yellow Granule	Eyeballing
Softening Point(°C)	95-105	ASTM E 28
Color Gardner	# 4-5	ASTM D 974
Acid Value (KOH mg/g)	≤1.0 or ≤0.1	ASTM D 1544
Ash Content%(wt)	≤0.1	ASTM D 1063

Recommended Loading

Footwear (sole, foxing) ................ 5–8 phr
Rubber goods (sheet, roller, belt) ..... 4–8 phr
└─ Tire tread
‑ Passenger / light-truck .............. 4–6 phr
‑ Truck / bus .......................... 6–8 phr

Processing Note:

Add together with rubber; no need to modify cure system. Store in a cool, dry place away from direct sunlight.

Hydrocarbon Resin C5 List:

Application	Base Polymer Main Content	Product Recommended
Masking/Packaging Tape	NR SIS SBS	HC5100
Pressure Sensitive Adhesive	NR SIS SBS	HC5100, HC5090
HMA	EVA	HC5100, HC5090
Bookbinding HMA	EVA	HC5100
Thermoplastic Road Marking Paint	FILLERS	HC52100, HC52100A
Sealants	BUTYL RUBBER	HC52100, HC5100
Rubber Compounding	NR BR SBR	DCPD, HC5100, HC52100

HC5100 Aliphatic Hydrocarbon Resin C5 for Rubber Application

Packing: 25kg in PE bag or Paper bag. With pallet or without pallet.

Storage: Kept in a low temperature, dry and ventilated place, avoid direct sunlight.

Shelf life: One year in ventilating, cool and dry area.
