Petrolium Resin C9 HT9140 Hydrocarbon Resin for Paints

Aromatic resins (C9 resins) are made from C9 hydrocarbon aromatics. Their composition depends on the hydrocarbon raw material (coal tar, crude oil). The softening points of these resins range over a wide range. Compared to C5 resins, they have a higher melt viscosity, are darker in color (dark yellow to brown) and have a higher softening point ranging from about 100 to 150°C. C9 resins are versatile resins that are compatible with many polymers.

Item NO.:
HT9140
EINECS No.:
265-116-8
CAS No.:
64742-16-1
Color Gardener:
#11- #18
Property:
This product is made by crack C9, through thermal and polymerization. It's a kind of granular solid with color from yellow to light yellow. It has the properties of good heat stability, solubility, water resistance and very good chemical stability over acid and alkali.

Inquire Now

Petrolium Resin C9 HT9140 Hydrocarbon Resin for EVA based Hot Melt Adhesive

Product Name

C9 Petroleum Hydrocarbon Resin (Aromatic Resin)

C9 Resin HC Series Hot Polymerization (C9 Thermal Hydrocarbon Resin)

Type

HT9140

Chemical Properties

HT9140 C9 Resin is made by C9 fraction, through catalytic polymerization.

High softening point Hydrocarbon resin C9 HT9140 is granular solid with the color of yellow to light brown.

HT9140 has the properties of good solubility, mutual solubility, water resistance, insulation and very good chemical stability over acid and alkali, and good adhesive strength and lower heat conduction, etc

Specifications

Test Item	Specification	Test Method
Appearance	Dark yellow or brown granular	Eyeballing
Softening Point	120-130	ASTM E 28
Color Gardner	# 11-# 18	ASTM D 974
Acid Value (KOH mg/g)	≤1.0	ASTM D 1544
Ash Content%(wt.)	≤0.1	ASTM D 1063

Petrolium Resin C9 Application

Paints mainly use C9 hydrocarbon resin with high softening points.

Petroleum resin C9 added to paints can increase:

» Final finishes of paints

» Adhesiveness of paint films and the hardness

» Resistance to acid and alkaline elements

Usually, HT9140 Petrolium Resin C9 which have high softening point are used for printing inks to increase the printing property they have as the resin provides the following advantages

» Colour spreading,

» Fast dry

» Brightening effects.

Related Products

C9 Petroleum Hydrocarbon Resin
Application	Base Polymer	Product Recommended
Carton Sealing Adhesive	EVA	HC9110
Woodworking Adhesive	EVA	HC9110, HC9120, HC9130
Hot Melt Adhesive Film	EVA	HC9110, HC9120
Shoe Adhesive	SBS, CR	HC9120, HT9100
Alkyd Paint	Long oil alkyd resin	HC9120, HT9120
Aluminium Paint	Aluminium paste	HC9100, HC9120
Off-Set Printing Ink	Phenolic resin	HC9120, HC9140, HC9120, HT9140
Rubber Compounding	NR, SBR	HC9100, HT9100
Asphalt Modification	Asphalt	HC9120, HC9140, HC9150, HT9120, HT9140
Concrete	Wax, Solvents	HC9100, HC9120, HT9120
